INA AXK0515-TV/0-10 Rulman

Özellikler

Marka	INA
Ürün No	AXK0515-TV/0-10 INA
Üretici No	0007938099065
EAN	4054364220402
Kategori	İtme Yatağı - İğne Makaralı

Ağırlık ve Boyutlar

İç (d) MM	5
Dış (D) MM	15
En (B) MM	2
İç (d) Inch	0.1969
Dış (D) Inch	0.5906
En (B) Inch	0.0787
Ağırlık	0.001 kg

Data from Schaeffler (medias)

Outside diameter (D c) mm	15
Rolling element diameter (D W) mm	2
Axial Static Load Rating C0a (N)	9200
Axial Dynamic Load Rating Ca (N)	4750
Hız sınırlaması (n G)	20500
Raceway dimension (E a) mm	14
Raceway dimension (E b) mm	6
Referans Hızı (n u03d1r)	13000
ECLASS number	23-05-11-90
ECLASS2 number	23-05-11-90
Medias description	Axial needle roller and cage assemblies, single direction, to DIN 5405-2

Suffix description

TV	Solid Cage Of Glass-Fibre Reinforced Polyamide, Ball Riding
/0-10	Micron - Needle Sort
