INA E50-XL-KLL Rulman

INA E50-XL-KLL
INA E50-XL-KLL rulman resim 1
INA E50-XL-KLL rulman resim 2
INA E50-XL-KLL rulman resim 3
INA E50-XL-KLL rulman resim 4
INA E50-XL-KLL rulman resim 5
INA E50-XL-KLL rulman resim 6
INA E50-XL-KLL rulman resim 7
Fiyatı: 1,512.20 ₺
Özellikler
Marka INA
Ürün No E50-XL-KLL INA
Üretici No 0008523920000
Alternatif Kodu E50-KLL
EAN 4012802799859
Kategori Muhafazalar İçin Rulmanlar
Ağırlık ve Boyutlar
İç (d) MM 50
Dış (D) MM 90
En (B) MM 62,8
İç (d) Inch 1.9685
Dış (D) Inch 3.5433
En (B) Inch 2.4724
Ağırlık 1 kg
Ürün Özellikleri
Fok 2L - Her İki Tarafta LS Contası
Yağlama Standart Yağlama
Özel Muamele No Special Treatment
Data from Schaeffler (medias)
Genişlik (b) mm 49,2
Locking collar total width (B 1) mm 62,8
Radial Static Load Rating C0r (N) 23200
Radial Dynamic Load Rating Cr (N) 37500
Temel statik yük derecesi, radyal (C 0r) "23200.0000"
ECLASS number 23-05-08-02
ECLASS2 number 23-05-08-02
Medias description Radial insert ball bearings E..-KLL, cylindrical outer ring, location by eccentric locking collar, L seals on both sides
Suffix description
XL X-Life
KRR Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
