INA EGW12-E50-Y Rulman

Özellikler

Marka	INA
Ürün No	EGW12-E50-Y INA
Üretici No	0708734530000
Alternatif Kodu	PAW12-P20
EAN	4012802755534
Kategori	Burçlanma

Ağırlık ve Boyutlar

İç (d) MM	12
Dış (D) MM	24
En (B) MM	1,5
İç (d) Inch	0.4724
Dış (D) Inch	0.9449
En (B) Inch	0.0591
Ağırlık	0.00263 kg

Data from Schaeffler (medias)

Wall thickness (s 3) mm	1,5
Axial Static Load Rating C0a (N)	47501
Axial Dynamic Load Rating Ca (N)	23800
ECLASS number	23-05-01-91
ECLASS2 number	23-05-01-91
Medias description	Thrust washer, low-maintenance, material in accordance with ISO 3547-4, with steel backing

Suffix description

E50	Steel Backing With Sintered Layer Of Tin Bronze. Pore Filling And Covering Layer (0,3 And 0,4mm, Resp.) Of PTFE With Friction-Reducing Additives
Y	Schaeffler Factory Code
