INA EGW18-E40-Z Rulman

Özellikler

Marka	INA
Ürün No	EGW18-E40-Z INA
Üretici No	0702320080000
Alternatif Kodu	PAW18P10
EAN	4012802759952
Kategori	Burçlanma

Ağırlık ve Boyutlar

İç (d) MM	18
Dış (D) MM	32
En (B) MM	1,5
İç (d) Inch	0.7087
Dış (D) Inch	1.2598
En (B) Inch	0.0591
Ağırlık	0.0061 kg

Data from Schaeffler (medias)

Wall thickness (s 3) mm	1,5
Axial Static Load Rating C0a (N)	137000
Axial Dynamic Load Rating Ca (N)	77000
ECLASS number	23-05-01-91
ECLASS2 number	23-05-01-91
Medias description	Thrust washer, maintenance-free, material in accordance with ISO 3547-4, with steel backing

Suffix description

E40	Steel Backing With Sintered Layer Of Tin Bronze. Pore Filling And Covering Layer (5 To 30µm) Of PTFE With Friction-Reduction Additives
Z	Schaeffler Factory Code
