INA GAKL16-PB Rulman

Özellikler

Marka	INA
Ürün No	GAKL16-PB INA
Üretici No	0066333660000
Alternatif Kodu	SALKAC16M
EAN	4012802524079
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	16
Dış (D) MM	43
En (B) MM	21
İç (d) Inch	0.6299
Dış (D) Inch	1.6929
En (B) Inch	0.8268
Ağırlık	0.19 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on Bronze

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	32
Radial Static Load Rating C0r (N)	45300
Width inner ring (B) mm	21
Radial Dynamic Load Rating Cr (N)	21400
Temel statik yük derecesi, radyal (C 0r)	"45300.0000"
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end with external thread, left hand thread, requiring maintenance, sliding contact surface: steel/bronze, DIN ISO 12240-4, dimension series K, type M, open design

Suffix description

PB	Sliding Contact Surface Is Steel/Bronze
