INA GAKL20-PW Rulman

Özellikler

Marka	INA
Ürün No	GAKL20-PW INA
Üretici No	0066309440000
Alternatif Kodu	SALKB20F
EAN	4012802523478
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	20
Dış (D) MM	50
En (B) MM	25
İç (d) Inch	0.7874
Dış (D) Inch	1.9685
En (B) Inch	0.9843
Ağırlık	0.34 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	40
Outer eye diameter (d 2) mm	50
Radial Static Load Rating C0r (N)	45600
Width inner ring (B) mm	25
Radial Dynamic Load Rating Cr (N)	56600
Temel statik yük derecesi, radyal (C 0r)	"45600.0000"
Total length external thread rod (l 2) mm	103
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end GAKL..-PW, external threads, maintenance-free

Suffix description

PW	Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film
