INA GAKR30-PB Rulman

Özellikler

Marka	INA
Ürün No	GAKR30-PB INA
Üretici No	0066335950000
Alternatif Kodu	SAKAC30M
EAN	4012802524499
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	30
Dış (D) MM	148
En (B) MM	37
İç (d) Inch	1.1811
Dış (D) Inch	5.8268
En (B) Inch	1.4567
Ağırlık	1.0394 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on Bronze

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	55
Radial Static Load Rating C0r (N)	95900
Width inner ring (B) mm	37
Radial Dynamic Load Rating Cr (N)	63500
Temel statik yük derecesi, radyal (C 0r)	"95900.0000"
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end with external thread, right hand thread, requiring maintenance, sliding contact surface: steel/bronze, DIN ISO 12240-4, dimension series K, type M, open design

Suffix description

PB	Sliding Contact Surface Is Steel/Bronze
