INA GAKSL30-PS Rulman

Özellikler

Marka	INA
Ürün No	GAKSL30-PS INA
Üretici No	0598910170000
EAN	4012802545067
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	30
Dış (D) MM	71
En (B) MM	37
İç (d) Inch	1.1811
Dış (D) Inch	2.7953
En (B) Inch	1.4567
Ağırlık	1.06 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	55
Outer eye diameter (d 2) mm	71
Radial Static Load Rating C0r (N)	47500
Width inner ring (B) mm	37
Radial Dynamic Load Rating Cr (N)	114000
Temel statik yük derecesi, radyal (C 0r)	"47500.0000"
Total length external thread rod (l 2) mm	146
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Corrosion-resistant rod end, with external thread, maintenance-free, sliding layer: PTFE film, DIN ISO 12240-4, dimension series K, type F, open design

Suffix description

PS	Special Steel, Maintenance Free
