INA GAKSL5-PS Rulman

Özellikler

Marka	INA
Ürün No	GAKSL5-PS INA
Üretici No	0598988600000
EAN	4012802545524
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	5
Dış (D) MM	19
En (B) MM	8
İç (d) Inch	0.1969
Dış (D) Inch	0.748
En (B) Inch	0.315
Ağırlık	0.01 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	13
Outer eye diameter (d 2) mm	19
Radial Static Load Rating C0r (N)	1800
Width inner ring (B) mm	8
Radial Dynamic Load Rating Cr (N)	6000
Temel statik yük derecesi, radyal (C 0r)	"1800.0000"
Total length external thread rod (l 2) mm	42,5
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Corrosion-resistant rod end, with external thread, maintenance-free, sliding layer: PTFE film, DIN ISO 12240-4, dimension series K, type F, open design

Suffix description

PS	Special Steel, Maintenance Free
