| Outside diameter bearing (D) mm |
19 |
| Outer eye diameter (d 2) mm |
25 |
| Radial Static Load Rating C0r (N) |
4600 |
| Width inner ring (B) mm |
12 |
| Radial Dynamic Load Rating Cr (N) |
12900 |
| Temel statik yük derecesi, radyal (C 0r) |
"4600.0000" |
| Total length external thread rod (l 2) mm |
54,5 |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Corrosion-resistant rod end, with external thread, right hand thread, maintenance-free, sliding layer: PTFE film, DIN ISO 12240-4, dimension series K, type F, open design |
