INA GE10-FW Rulman
Fiyatı: 896.34 ₺
Özellikler
| Marka | INA |
| Ürün No | GE10-FW INA |
| Üretici No | 0066497180000 |
| Alternatif Kodu |
GEH10C |
| EAN | 4012802531176 |
| Kategori | Küresel Düz Yatak |
| İç (d) MM | 10 |
| Dış (D) MM | 22 |
| En (B) MM | 12 |
| İç (d) Inch | 0.3937 |
| Dış (D) Inch | 0.8661 |
| En (B) Inch | 0.4724 |
| Ağırlık | 0.0197 kg |
| Fok | Kapaksız |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 22 |
| Radial Static Load Rating C0r (N) | 28400 |
| Width inner ring (B) mm | 12 |
| Radial Dynamic Load Rating Cr (N) | 11300 |
| Temel statik yük derecesi, radyal (C 0r) | "28400.0000" |
| ECLASS number | 23-05-01-06 |
| ECLASS2 number | 23-05-01-06 |
| Medias description | Radial spherical plain bearing, maintenance-free, sliding layer: PTFE composite, inner ring curved surface with hard chromium coating DIN ISO 12240-1, dimension series G, open design |
| FW | Sliding Contact Surface Hard Chromium/PTFE (Polyetrafluoroethylene) Composite, Wide Inner Ring |
