INA GE120-FW-2RS-C Rulman
Fiyatı: 53,167.48 ₺
Özellikler
| Marka | INA |
| Ürün No | GE120-FW-2RS-C INA |
| Üretici No | 0066506510000 |
| EAN | 4012802532166 |
| Kategori | Küresel Düz Yatak |
| İç (d) MM | 120 |
| Dış (D) MM | 210 |
| En (B) MM | 115 |
| İç (d) Inch | 4.7244 |
| Dış (D) Inch | 8.2677 |
| En (B) Inch | 4.5276 |
| Ağırlık | 14.6 kg |
| Fok | 2RS - İki Tarafta Kauçuk Conta |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 210 |
| Radial Static Load Rating C0r (N) | 5040000 |
| Width inner ring (B) mm | 115 |
| Radial Dynamic Load Rating Cr (N) | 3020000 |
| Temel statik yük derecesi, radyal (C 0r) | "5040000.0000" |
| ECLASS number | 23-05-01-06 |
| ECLASS2 number | 23-05-01-06 |
| Medias description | Radial spherical plain bearing, maintenance-free, sliding layer: ELGOGLIDE, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series G, sealed |
| FW | Sliding Contact Surface Hard Chromium/PTFE (Polyetrafluoroethylene) Composite, Wide Inner Ring |
| 2RS | Lip Seals On Both Sides |
| C | Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
