INA GE140-SW-A Rulman

Özellikler

Marka	INA
Ürün No	GE140-SW-A INA
Üretici No	0066521740000
EAN	4012802532883
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	140
Dış (D) MM	210
En (B) MM	45
İç (d) Inch	5.5118
Dış (D) Inch	8.2677
En (B) Inch	1.7717
Ağırlık	6.486 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	210
Height (T) mm	45
Radial Static Load Rating C0r (N)	3320000
Width inner ring (B) mm	42
Radial Dynamic Load Rating Cr (N)	1990000
Temel statik yük derecesi, radyal (C 0r)	"3320000.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Angular contact spherical plain bearing, maintenance-free, DIN ISO 12240-2, inner ring curved surface with hard chromium coating, open design

Suffix description

SW	Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene))
A	Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard)
