INA GE15-FW Rulman

Özellikler

Marka	INA
Ürün No	GE15-FW INA
Üretici No	0066497930000
Alternatif Kodu	GEH15C
EAN	4012802531312
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	15
Dış (D) MM	30
En (B) MM	16
İç (d) Inch	0.5906
Dış (D) Inch	1.1811
En (B) Inch	0.6299
Ağırlık	0.0481 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	30
Radial Static Load Rating C0r (N)	56300
Width inner ring (B) mm	16
Radial Dynamic Load Rating Cr (N)	22500
Temel statik yük derecesi, radyal (C 0r)	"56300.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Radial spherical plain bearing, maintenance-free, sliding layer: PTFE composite, inner ring curved surface with hard chromium coating DIN ISO 12240-1, dimension series G, open design

Suffix description

FW	Sliding Contact Surface Hard Chromium/PTFE (Polyetrafluoroethylene) Composite, Wide Inner Ring
