INA GE15-UK Rulman

Özellikler

Marka	INA
Ürün No	GE15-UK INA
Üretici No	0066498070000
Alternatif Kodu	GE15C
EAN	4012802531329
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	15
Dış (D) MM	26
En (B) MM	12
İç (d) Inch	0.5906
Dış (D) Inch	1.0236
En (B) Inch	0.4724
Ağırlık	0.0266 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	26
Radial Static Load Rating C0r (N)	44600
Width inner ring (B) mm	12
Radial Dynamic Load Rating Cr (N)	17800
Temel statik yük derecesi, radyal (C 0r)	"44600.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Radial spherical plain bearing, maintenance-free, sliding layer: PTFE composite, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series E, open design

Suffix description

UK	Sliding Contact Surface Hard Chromium/PTFE Composite
