INA GE16-LO Rulman

Özellikler

Marka	INA
Ürün No	GE16-LO INA
Üretici No	0066526540000
EAN	4012802533187
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	16
Dış (D) MM	28
En (B) MM	16
İç (d) Inch	0.6299
Dış (D) Inch	1.1024
En (B) Inch	0.6299
Ağırlık	0.035 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on Steel

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	28
Radial Static Load Rating C0r (N)	88600
Width inner ring (B) mm	16
Radial Dynamic Load Rating Cr (N)	17700
Temel statik yük derecesi, radyal (C 0r)	"90900.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Radial spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-1, dimension series W, cylindrical extensions on inner ring, open design

Suffix description

LO	Sliding Contact Surface Is Steel/Steel, Inner Ring Extended On Both Sides, Single Axial Split In Outer Ring
