INA GE20-UK Rulman

Özellikler

Marka	INA
Ürün No	GE20-UK INA
Üretici No	0066500070000
Alternatif Kodu	GE20C
EAN	4012802531596
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	20
Dış (D) MM	35
En (B) MM	16
İç (d) Inch	0.7874
Dış (D) Inch	1.378
En (B) Inch	0.6299
Ağırlık	0.0645 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	35
Radial Static Load Rating C0r (N)	78300
Width inner ring (B) mm	16
Radial Dynamic Load Rating Cr (N)	31300
Temel statik yük derecesi, radyal (C 0r)	"78300.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Radial spherical plain bearing, maintenance-free, sliding layer: PTFE composite, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series E, open design

Suffix description

UK	Sliding Contact Surface Hard Chromium/PTFE Composite
