INA GE28-SW-A Rulman

Özellikler

Marka	INA
Ürün No	GE28-SW-A INA
Üretici No	0066515500000
EAN	4012802532470
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	28
Dış (D) MM	52
En (B) MM	16
İç (d) Inch	1.1024
Dış (D) Inch	2.0472
En (B) Inch	0.6299
Ağırlık	0.18 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	52
Height (T) mm	16
Radial Static Load Rating C0r (N)	288000
Width inner ring (B) mm	15
Radial Dynamic Load Rating Cr (N)	173000
Temel statik yük derecesi, radyal (C 0r)	"288000.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Angular contact spherical plain bearing, maintenance-free, DIN ISO 12240-2, inner ring curved surface with hard chromium coating, open design

Suffix description

SW	Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene))
A	Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard)
