INA GE30-UK Rulman

Özellikler

Marka	INA
Ürün No	GE30-UK INA
Üretici No	0066501390000
Alternatif Kodu	GE30C
EAN	4012802531787
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	30
Dış (D) MM	47
En (B) MM	22
İç (d) Inch	1.1811
Dış (D) Inch	1.8504
En (B) Inch	0.8661
Ağırlık	0.1482 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	47
Radial Static Load Rating C0r (N)	165000
Width inner ring (B) mm	22
Radial Dynamic Load Rating Cr (N)	65900
Temel statik yük derecesi, radyal (C 0r)	"165000.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Radial spherical plain bearing, maintenance-free, sliding layer: PTFE composite, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series E, open design

Suffix description

UK	Sliding Contact Surface Hard Chromium/PTFE Composite
