INA GE35-FW-2RS-A Rulman
Fiyatı: 2,188.26 ₺
Özellikler
| Marka | INA |
| Ürün No | GE35-FW-2RS-A INA |
| Üretici No | 0066501980000 |
| Alternatif Kodu |
GEH35TXE-2RS |
| EAN | 4012802531770 |
| Kategori | Küresel Düz Yatak |
| İç (d) MM | 35 |
| Dış (D) MM | 62 |
| En (B) MM | 35 |
| İç (d) Inch | 1.378 |
| Dış (D) Inch | 2.4409 |
| En (B) Inch | 1.378 |
| Ağırlık | 0.39 kg |
| Fok | 2RS - İki Tarafta Kauçuk Conta |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 62 |
| Radial Static Load Rating C0r (N) | 466000 |
| Width inner ring (B) mm | 35 |
| Radial Dynamic Load Rating Cr (N) | 280000 |
| Temel statik yük derecesi, radyal (C 0r) | "466000.0000" |
| ECLASS number | 23-05-01-06 |
| ECLASS2 number | 23-05-01-06 |
| Medias description | Radial spherical plain bearing, maintenance-free, sliding layer: ELGOGLIDE, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series G, sealed |
| FW | Sliding Contact Surface Hard Chromium/PTFE (Polyetrafluoroethylene) Composite, Wide Inner Ring |
| 2RS | Lip Seals On Both Sides |
| A | Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
