INA GE35-SW-A Rulman

Özellikler

Marka	INA
Ürün No	GE35-SW-A INA
Üretici No	0066516580000
EAN	4012802532524
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	35
Dış (D) MM	62
En (B) MM	18
İç (d) Inch	1.378
Dış (D) Inch	2.4409
En (B) Inch	0.7087
Ağırlık	0.2523 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	62
Height (T) mm	18
Radial Static Load Rating C0r (N)	393000
Width inner ring (B) mm	17
Radial Dynamic Load Rating Cr (N)	236000
Temel statik yük derecesi, radyal (C 0r)	"393000.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Angular contact spherical plain bearing, maintenance-free, DIN ISO 12240-2, inner ring curved surface with hard chromium coating, open design

Suffix description

SW	Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene))
A	Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard)
