INA GE35-XL-KRR-B-FA164 Rulman

Özellikler

Marka	INA
Ürün No	GE35-XL-KRR-B-FA164 INA
Üretici No	0009510720000
Alternatif Kodu	GE35-KRR-B-FA164
EAN	4012802823905
Kategori	Muhafazalar İçin Rulmanlar

Ağırlık ve Boyutlar

İç (d) MM	35
Dış (D) MM	72
En (B) MM	51,3
İç (d) Inch	1.378
Dış (D) Inch	2.8346
En (B) Inch	2.0197
Ağırlık	0.525 kg

Ürün Özellikleri

Fok	2F - Y-Rulmanlar için Standart Conta
Yağlama	Standart Yağlama
Özel Muamele	E - High Temp Design Up to +250°C

Data from Schaeffler (medias)

Outside diameter (D SP) mm	72
Genişlik (b) mm	37,7
Locking collar total width (B 1) mm	51,3
Radial Static Load Rating C0r (N)	15300
Radial Dynamic Load Rating Cr (N)	27500
Temel statik yük derecesi, radyal (C 0r)	"15300.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearings GE..-KRR-B-FA164, spherical outer ring, location by eccentric locking collar, R seals on both sides, for temperatures up to +250°C

Suffix description

XL	X-Life
KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
FA164	High Temperature Design Up To +250°C
