INA GE45-SW-A Rulman
Fiyatı: 1,870.90 ₺
Özellikler
| Marka | INA |
| Ürün No | GE45-SW-A INA |
| Üretici No | 0066517390000 |
| EAN | 4012802532593 |
| Kategori | Küresel Düz Yatak |
| İç (d) MM | 45 |
| Dış (D) MM | 75 |
| En (B) MM | 20 |
| İç (d) Inch | 1.7717 |
| Dış (D) Inch | 2.9528 |
| En (B) Inch | 0.7874 |
| Ağırlık | 0.385 kg |
| Fok | Kapaksız |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 75 |
| Height (T) mm | 20 |
| Radial Static Load Rating C0r (N) | 532000 |
| Width inner ring (B) mm | 19 |
| Radial Dynamic Load Rating Cr (N) | 319000 |
| Temel statik yük derecesi, radyal (C 0r) | "532000.0000" |
| ECLASS number | 23-05-01-06 |
| ECLASS2 number | 23-05-01-06 |
| Medias description | Angular contact spherical plain bearing, maintenance-free, DIN ISO 12240-2, inner ring curved surface with hard chromium coating, open design |
| SW | Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene)) |
| A | Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
