INA GE55-SW-A Rulman
Fiyatı: 8,509.89 ₺
Özellikler
| Marka | INA |
| Ürün No | GE55-SW-A INA |
| Üretici No | 0066518010000 |
| EAN | 4012802532692 |
| Kategori | Küresel Düz Yatak |
| İç (d) MM | 55 |
| Dış (D) MM | 90 |
| En (B) MM | 23 |
| İç (d) Inch | 2.1654 |
| Dış (D) Inch | 3.5433 |
| En (B) Inch | 0.9055 |
| Ağırlık | 0.69 kg |
| Fok | Kapaksız |
| Contact Material | Steel on PTFE |
| Outside diameter bearing (D) mm | 90 |
| Height (T) mm | 23 |
| Radial Static Load Rating C0r (N) | 746000 |
| Width inner ring (B) mm | 22 |
| Radial Dynamic Load Rating Cr (N) | 448000 |
| Temel statik yük derecesi, radyal (C 0r) | "746000.0000" |
| ECLASS number | 23-05-01-06 |
| ECLASS2 number | 23-05-01-06 |
| Medias description | Angular contact spherical plain bearing, maintenance-free, DIN ISO 12240-2, inner ring curved surface with hard chromium coating, open design |
| SW | Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene)) |
| A | Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
