INA GE60-XL-KRR-B-FA164 Rulman
Fiyatı: 20,788.30 ₺
Özellikler
| Marka | INA |
| Ürün No | GE60-XL-KRR-B-FA164 INA |
| Üretici No | 0009807650000 |
| Alternatif Kodu |
GE60-KRR-B-FA164 |
| EAN | 4012802818253 |
| Kategori | Muhafazalar İçin Rulmanlar |
| İç (d) MM | 60 |
| Dış (D) MM | 110 |
| En (B) MM | 77,9 |
| İç (d) Inch | 2.3622 |
| Dış (D) Inch | 4.3307 |
| En (B) Inch | 3.0669 |
| Ağırlık | 1.6 kg |
| Fok | 2F - Y-Rulmanlar için Standart Conta |
| Yağlama | Standart Yağlama |
| Özel Muamele | E - High Temp Design Up to +250°C |
| Outside diameter (D SP) mm | 110 |
| Genişlik (b) mm | 61,9 |
| Locking collar total width (B 1) mm | 77,9 |
| Radial Static Load Rating C0r (N) | 36000 |
| Radial Dynamic Load Rating Cr (N) | 56000 |
| Temel statik yük derecesi, radyal (C 0r) | "36000.0000" |
| ECLASS number | 23-05-08-02 |
| ECLASS2 number | 23-05-08-02 |
| Medias description | Radial insert ball bearings GE..-KRR-B-FA164, spherical outer ring, location by eccentric locking collar, R seals on both sides, for temperatures up to +250°C |
| XL | X-Life |
| KRR | Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B | Bearing With Spherical Outer Ring |
| FA164 | High Temperature Design Up To +250°C |
