INA GE65-SW-A Rulman

Özellikler

Marka	INA
Ürün No	GE65-SW-A INA
Üretici No	0066518790000
EAN	4012802532685
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	65
Dış (D) MM	100
En (B) MM	23
İç (d) Inch	2.5591
Dış (D) Inch	3.937
En (B) Inch	0.9055
Ağırlık	0.8 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	100
Height (T) mm	23
Radial Static Load Rating C0r (N)	867000
Width inner ring (B) mm	22
Radial Dynamic Load Rating Cr (N)	520000
Temel statik yük derecesi, radyal (C 0r)	"867000.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Angular contact spherical plain bearing, maintenance-free, DIN ISO 12240-2, inner ring curved surface with hard chromium coating, open design

Suffix description

SW	Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene))
A	Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard)
