INA GE90-SX Rulman

Özellikler

Marka	INA
Ürün No	GE90-SX INA
Üretici No	0066544520000
EAN	4012802534948
Kategori	Küresel Düz Yatak

Ağırlık ve Boyutlar

İç (d) MM	90
Dış (D) MM	140
En (B) MM	32
İç (d) Inch	3.5433
Dış (D) Inch	5.5118
En (B) Inch	1.2598
Ağırlık	2.1 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on Steel

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	140
Height (T) mm	32
Radial Static Load Rating C0r (N)	1570000
Radial Dynamic Load Rating Cr (N)	314000
Temel statik yük derecesi, radyal (C 0r)	"1570000.0000"
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Angular contact spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-2, open design

Suffix description

SX	Angular Contact Spherical Plain Bearing Requiring Maintenance To Iso 12 2402, Mounting Dimensions As For Tapered Roller Bearings To Din 720, 320X, Sliding Contact Surface Steel/Steel
