INA GIHRK20-UK-2RS Rulman

Özellikler

Marka	INA
Ürün No	GIHRK20-UK-2RS INA
Üretici No	0130274760000
EAN	4012802538731
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	20
Dış (D) MM	56
En (B) MM	16
İç (d) Inch	0.7874
Dış (D) Inch	2.2047
En (B) Inch	0.6299
Ağırlık	0.4171 kg

Ürün Özellikleri

Fok	2RS - İki Tarafta Kauçuk Conta
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	35
Radial Static Load Rating C0r (N)	81100
Width inner ring (B) mm	16
Radial Dynamic Load Rating Cr (N)	67900
Temel statik yük derecesi, radyal (C 0r)	"81100.0000"
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Hydraulic rod end, with thread clamping device, right hand thread, maintenance-free, sliding layer: ELGOGLIDE, sealed design

Suffix description

UK	Sliding Contact Surface Hard Chromium/PTFE Composite
2RS	Lip Seals On Both Sides
