INA GIKL16-PW Rulman

Özellikler

Marka	INA
Ürün No	GIKL16-PW INA
Üretici No	0066348770000
EAN	4012802525878
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	16
Dış (D) MM	42
En (B) MM	21
İç (d) Inch	0.6299
Dış (D) Inch	1.6535
En (B) Inch	0.8268
Ağırlık	0.21 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	32
Radial Static Load Rating C0r (N)	45200
Width inner ring (B) mm	21
Radial Dynamic Load Rating Cr (N)	39000
Temel statik yük derecesi, radyal (C 0r)	"45200.0000"
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end with internal thread, left hand thread maintenance-free, sliding layer: PTFE film brass outer ring, DIN ISO 12240-4, dimension series K, type F, open design

Suffix description

PW	Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film
