INA GIKL30-PB Rulman

Özellikler

Marka	INA
Ürün No	GIKL30-PB INA
Üretici No	0066349070000
Alternatif Kodu	SILKAC30M
EAN	4012802525847
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	30
Dış (D) MM	70
En (B) MM	37
İç (d) Inch	1.1811
Dış (D) Inch	2.7559
En (B) Inch	1.4567
Ağırlık	1.15 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on Bronze

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	55
Radial Static Load Rating C0r (N)	95900
Width inner ring (B) mm	37
Radial Dynamic Load Rating Cr (N)	63500
Temel statik yük derecesi, radyal (C 0r)	"95900.0000"
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end with internal thread, left hand thread, requiring maintenance, DIN ISO 12240-4. dimension series K, type F, open design

Suffix description

PB	Sliding Contact Surface Is Steel/Bronze
