INA GIKR25-PB Rulman

Özellikler

Marka	INA
Ürün No	GIKR25-PB INA
Üretici No	0066350590000
Alternatif Kodu	SIKAC25M
EAN	4012802526172
Kategori	Çubuk Ucu

Ağırlık ve Boyutlar

İç (d) MM	25
Dış (D) MM	60
En (B) MM	31
İç (d) Inch	0.9843
Dış (D) Inch	2.3622
En (B) Inch	1.2205
Ağırlık	0.7345 kg

Ürün Özellikleri

Fok	Kapaksız
Contact Material	Steel on Bronze

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	47
Radial Static Load Rating C0r (N)	72900
Width inner ring (B) mm	31
Radial Dynamic Load Rating Cr (N)	47100
Temel statik yük derecesi, radyal (C 0r)	"72900.0000"
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end with internal thread, right hand thread requiring maintenance, DIN ISO 12240-4. dimension series K, type F, open design

Suffix description

PB	Sliding Contact Surface Is Steel/Bronze
