INA GIR40-DO-2RS Rulman
Fiyatı: 4,273.71 ₺
Özellikler
| Marka | INA |
| Ürün No | GIR40-DO-2RS INA |
| Üretici No | 0066355980000 |
| Alternatif Kodu |
GIR40ES-2RS |
| EAN | 4012802526967 |
| Kategori | Çubuk Ucu |
| Dış (D) MM | 94 |
| En (B) MM | 28 |
| Dış (D) Inch | 3.7008 |
| En (B) Inch | 1.1024 |
| Ağırlık | 2.2 kg |
| Fok | 2RS - İki Tarafta Kauçuk Conta |
| Contact Material | Steel on Steel |
| Outside diameter bearing (D) mm | 62 |
| Radial Static Load Rating C0r (N) | 194000 |
| Width inner ring (B) mm | 28 |
| Radial Dynamic Load Rating Cr (N) | 99100 |
| Temel statik yük derecesi, radyal (C 0r) | "194000.0000" |
| ECLASS number | 23-05-01-05 |
| ECLASS2 number | 23-05-01-05 |
| Medias description | Rod end with internal thread, right hand thread, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-4, dimension series E, type F, sealed |
| DO | Sliding Contact Surface Steel/Steel & Inner And Outer Ring Hardened |
| 2RS | Lip Seals On Both Sides |
