INA GNE90-KRR-B-FA107 Rulman
Fiyatı: 12,790.81 ₺
Özellikler
| Marka | INA |
| Ürün No | GNE90-KRR-B-FA107 INA |
| Üretici No | 0004880620000 |
| EAN | 4012802784886 |
| Kategori | Muhafazalar İçin Rulmanlar |
| İç (d) MM | 90 |
| Dış (D) MM | 190 |
| En (B) MM | 101 |
| İç (d) Inch | 3.5433 |
| Dış (D) Inch | 7.4803 |
| En (B) Inch | 3.9764 |
| Ağırlık | 9.3 kg |
| Fok | 2F - Y-Rulmanlar için Standart Conta |
| Yağlama | Standart Yağlama |
| Özel Muamele | I - Lubr Holes on Locating Side |
| Outside diameter (D SP) mm | 190 |
| Genişlik (b) mm | 77,5 |
| Locking collar total width (B 1) mm | 101 |
| Radial Static Load Rating C0r (N) | 107000 |
| Radial Dynamic Load Rating Cr (N) | 151000 |
| Temel statik yük derecesi, radyal (C 0r) | "107000.0000" |
| ECLASS number | 23-05-08-02 |
| ECLASS2 number | 23-05-08-02 |
| Medias description | Radial insert ball bearing GNE..-KRR-B |
| KRR | Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B | Bearing With Spherical Outer Ring |
| FA107 | Bearing With Lubrication Holes On The Locating Side |
