INA GYE15-KRR-B-VA-HLA Rulman

Özellikler

Marka	INA
Ürün No	GYE15-KRR-B-VA-HLA INA
Üretici No	0530918840000
Alternatif Kodu	GYE15-KRR-B-VA
EAN	4047643202695
Kategori	Muhafazalar İçin Rulmanlar

Ağırlık ve Boyutlar

İç (d) MM	15
Dış (D) MM	40
En (B) MM	25
İç (d) Inch	0.5906
Dış (D) Inch	1.5748
En (B) Inch	0.9843
Ağırlık	0.105 kg

Ürün Özellikleri

Fok	2F - Y-Rulmanlar için Standart Conta
Yağlama	Standart Yağlama
Özel Muamele	Stainless Steel Bearing

Data from Schaeffler (medias)

Outside diameter (D SP) mm	40
Genişlik (b) mm	25
Radial Static Load Rating C0r (N)	4550
Radial Dynamic Load Rating Cr (N)	9200
Temel statik yük derecesi, radyal (C 0r)	"4550.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearing GYE..-KRR-B-VA

Suffix description

KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
VA	Corrosion-Resistant Design Made From High Alloy Rolling Bearing Steel
HLA	Factory Location Code, No Additional Meaning. Can Be Used As Standard
