INA GYE30-KRR-B-VA-HLA Rulman

Özellikler

Marka	INA
Ürün No	GYE30-KRR-B-VA-HLA INA
Üretici No	0510621940000
Alternatif Kodu	GYE30-KRR-B-VA
EAN	4047643203104
Kategori	Muhafazalar İçin Rulmanlar

Ağırlık ve Boyutlar

İç (d) MM	30
Dış (D) MM	62
En (B) MM	38,1
İç (d) Inch	1.1811
Dış (D) Inch	2.4409
En (B) Inch	1.5
Ağırlık	0.298 kg

Ürün Özellikleri

Fok	2F - Y-Rulmanlar için Standart Conta
Yağlama	Standart Yağlama
Özel Muamele	Stainless Steel Bearing

Data from Schaeffler (medias)

Outside diameter (D SP) mm	62
Genişlik (b) mm	38,1
Radial Static Load Rating C0r (N)	10700
Radial Dynamic Load Rating Cr (N)	18700
Temel statik yük derecesi, radyal (C 0r)	"10700.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearing GYE..-KRR-B-VA

Suffix description

KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
VA	Corrosion-Resistant Design Made From High Alloy Rolling Bearing Steel
HLA	Factory Location Code, No Additional Meaning. Can Be Used As Standard
