INA GYE50-KRR-B-FA107 Rulman

Özellikler

Marka	INA
Ürün No	GYE50-KRR-B-FA107 INA
Üretici No	0031992070000
EAN	4012802811933
Kategori	Muhafazalar İçin Rulmanlar

Ağırlık ve Boyutlar

İç (d) MM	50
Dış (D) MM	90
En (B) MM	51,6
İç (d) Inch	1.9685
Dış (D) Inch	3.5433
En (B) Inch	2.0315
Ağırlık	0.746 kg

Ürün Özellikleri

Fok	2F - Y-Rulmanlar için Standart Conta
Yağlama	Standart Yağlama
Özel Muamele	I - Lubr Holes on Locating Side

Data from Schaeffler (medias)

Outside diameter (D SP) mm	90
Genişlik (b) mm	51,6
Radial Static Load Rating C0r (N)	23200
Radial Dynamic Load Rating Cr (N)	37500
Temel statik yük derecesi, radyal (C 0r)	"23200.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearing GYE..-KRR-B

Suffix description

KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
FA107	Bearing With Lubrication Holes On The Locating Side
