INA K100X108X27-A/0-7 Rulman

INA K100X108X27-A/0-7
INA K100X108X27-A/0-7 rulman resim 1
INA K100X108X27-A/0-7 rulman resim 2
INA K100X108X27-A/0-7 rulman resim 3
INA K100X108X27-A/0-7 rulman resim 4
Fiyatı: 1,722.08 ₺
Özellikler
Marka INA
Ürün No K100X108X27-A/0-7 INA
Üretici No 0001725456063
EAN 4012802700145
Kategori İğne Makaralı ve Kafes Tertibatı
Ağırlık ve Boyutlar
İç (d) MM 100
Dış (D) MM 108
En (B) MM 27
İç (d) Inch 3.937
Dış (D) Inch 4.252
En (B) Inch 1.063
Ağırlık 0.176 kg
Ürün Özellikleri
Fok Kapaksız
Data from Schaeffler (medias)
Outside diameter of needle roller complement (E w) mm 108
Width (B c) mm 27
Radial Static Load Rating C0r (N) 143000
Radial Dynamic Load Rating Cr (N) 57000
Hız sınırlaması (n G) 4700
Referans Hızı (n u03d1r) 3200
ECLASS number 23-05-09-04
ECLASS2 number 23-05-09-04
Medias description Needle roller cage assembly K, single row
Suffix description
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
/0-7 Micron - Needle Sort
