INA KR22-PP-A-NIP-VD/MON Rulman

Özellikler

Marka	INA
Ürün No	KR22-PP-A-NIP-VD/MON INA
Üretici No	0055454120120
EAN	4012802573947
Kategori	Kam Takipçisi

Ağırlık ve Boyutlar

İç (d) MM	10
Dış (D) MM	22
En (B) MM	12
İç (d) Inch	0.3937
Dış (D) Inch	0.8661
En (B) Inch	0.4724
Ağırlık	0.045 kg

Ürün Özellikleri

Fok	2L - Her İki Tarafta LS Contası
Excenterring	Other Mounting Method
Running Surface	Standard

Data from Schaeffler (medias)

Fit diameter of roller stud / stud (d 1) mm	10
Width of the roller stud (B) mm	36
Basic dynamic load rating, radial (C r w)	4500
Temel statik yük derecesi, radyal (C 0r)	5400
Speed on permanent grease lubrication (n D G)	8000
ECLASS number	23-05-15-02
ECLASS2 number	23-05-15-02

Suffix description

PP	Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100u2103
A	Improved Crowned Profile Of The Outside Running Surface
NIP/MON	Drive-Fit Lubrication Nipple And Or Closing Plug Mounted
