INA KR22-X-PP-A Rulman

Özellikler

Marka	INA
Ürün No	KR22-X-PP-A INA
Üretici No	0057450470000
Alternatif Kodu	KR22.2RSDZ
EAN	4012802418125
Kategori	Kam Takipçisi

Ağırlık ve Boyutlar

İç (d) MM	10
Dış (D) MM	22
En (B) MM	12
İç (d) Inch	0.3937
Dış (D) Inch	0.8661
En (B) Inch	0.4724
Ağırlık	0.044 kg

Ürün Özellikleri

Fok	2L - Her İki Tarafta LS Contası
Excenterring	Other Mounting Method
Running Surface	Cylindrical

Data from Schaeffler (medias)

Fit diameter of roller stud / stud (d 1) mm	10
Width of the roller stud (B) mm	36
Basic dynamic load rating, radial (C r w)	4500
Temel statik yük derecesi, radyal (C 0r)	5400
Speed on permanent grease lubrication (n D G)	8000
ECLASS number	23-05-15-02
ECLASS2 number	23-05-15-02
Medias description	Stud type track rollers KR..-PP, with axial guidance, plastic axial plain washers on both sides

Suffix description

X	Cylindrical Running Surface
PP	Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100u2103
A	Design Modification
