INA KR5203-2RS Rulman
Fiyatı: 1,655.30 ₺
Özellikler
| Marka | INA |
| Ürün No | KR5203-2RS INA |
| Üretici No | 0008764880000 |
| Alternatif Kodu |
KR5203NPPU |
| EAN | 4012802795462 |
| Kategori | Kam Takipçisi |
| İç (d) MM | 18 |
| Dış (D) MM | 47 |
| En (B) MM | 17,5 |
| İç (d) Inch | 0.7087 |
| Dış (D) Inch | 1.8504 |
| En (B) Inch | 0.689 |
| Ağırlık | 0.29 kg |
| Fok | 2RS - İki Tarafta Kauçuk Conta |
| Excenterring | Other Mounting Method |
| Running Surface | Standard |
| Fit diameter of roller stud / stud (d 1) mm | 18 |
| Genişlik (b) mm | 58,8 |
| Basic dynamic load rating, radial (C r w) | 12700 |
| Temel statik yük derecesi, radyal (C 0r) | 8500 |
| Fatigue load limit, radial (C ur w) | 425 |
| Speed on permanent grease lubrication (n D G) | 5500 |
| ECLASS number | 23-05-15-90 |
| ECLASS2 number | 23-05-15-90 |
| Medias description | Stud type track rollers KR52..-2RS, double row, lip seals on both sides |
| 2RS | Rubber Seals At Each Side Of The Bearing, Temperature Range -30u2103/+120u2103 |
