INA KR5204-2RS Rulman
Fiyatı: 1,804.76 ₺
Özellikler
| Marka | INA |
| Ürün No | KR5204-2RS INA |
| Üretici No | 0008443060000 |
| Alternatif Kodu |
KR5204NPPU |
| EAN | 4012802801804 |
| Kategori | Kam Takipçisi |
| İç (d) MM | 20 |
| Dış (D) MM | 52 |
| En (B) MM | 20,6 |
| İç (d) Inch | 0.7874 |
| Dış (D) Inch | 2.0472 |
| En (B) Inch | 0.811 |
| Ağırlık | 0.365 kg |
| Fok | 2RS - İki Tarafta Kauçuk Conta |
| Excenterring | Other Mounting Method |
| Running Surface | Standard |
| Fit diameter of roller stud / stud (d 1) mm | 20 |
| Genişlik (b) mm | 63,6 |
| Basic dynamic load rating, radial (C r w) | 15800 |
| Temel statik yük derecesi, radyal (C 0r) | 10800 |
| Fatigue load limit, radial (C ur w) | 550 |
| Speed on permanent grease lubrication (n D G) | 5000 |
| ECLASS number | 23-05-15-90 |
| ECLASS2 number | 23-05-15-90 |
| Medias description | Stud type track rollers KR52..-2RS, double row, lip seals on both sides |
| 2RS | Rubber Seals At Each Side Of The Bearing, Temperature Range -30u2103/+120u2103 |
