INA KRVE26-PP-A Rulman

Özellikler

Marka	INA
Ürün No	KRVE26-PP-A INA
Üretici No	0057466550000
EAN	4012802420371
Kategori	Kam Takipçisi

Ağırlık ve Boyutlar

İç (d) MM	13
Dış (D) MM	26
En (B) MM	12
İç (d) Inch	0.5118
Dış (D) Inch	1.0236
En (B) Inch	0.4724
Ağırlık	0.06 kg

Ürün Özellikleri

Fok	2L - Her İki Tarafta LS Contası
Excenterring	E - Excenterring with Inbus Mount
Running Surface	Standard

Data from Schaeffler (medias)

Fit diameter of roller stud / stud (d 1) mm	10
Genişlik (b) mm	36
Basic dynamic load rating, radial (C r w)	7300
Temel statik yük derecesi, radyal (C 0r)	11600
Speed on permanent grease lubrication (n D G)	2600
ECLASS number	23-05-15-02
ECLASS2 number	23-05-15-02
Medias description	Yoke type track roller KRVE..-PP-A, full complement needle roller set, with axial guidance, with eccentric

Suffix description

PP	Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100u2103
A	Alteration In Internal Construction. Identical To Old Notation
