| Width carriage (B) mm |
60 |
| Overall length carriage (L) mm |
91,6 |
| Dynamic load rating, load direction I: compressive load (I C) |
40000 |
| Static load rating, load direction I: compressive load (I C 0) |
80000 |
| Dynamic load rating, load direction II: tensile load (II C) |
37800 |
| Static load rating, load direction II: tensile load (II C 0) |
60000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
40000 |
| Static load rating, Load direction III: lateral load (III C 0) |
62000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
High, narrow carriage for six-row linear recirculating ball bearing and guideway assembly |
