INA KWSE35-RROC-V2-G3 Rulman

Özellikler

Marka	INA
Ürün No	KWSE35-RROC-V2-G3 INA
Üretici No	0785730500340
Alternatif Kodu	KWSE35-RROC-G3-V2
EAN	4054362956457
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	34
Dış (D) MM	100
En (B) MM	41,4
İç (d) Inch	1.3386
Dış (D) Inch	3.937
En (B) Inch	1.6299
Ağırlık	1.5 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	100
Overall length carriage (L) mm	107,2
Dynamic load rating, load direction I: compressive load (I C)	55000
Static load rating, load direction I: compressive load (I C 0)	102000
Dynamic load rating, load direction II: tensile load (II C)	53300
Static load rating, load direction II: tensile load (II C 0)	82400
Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C)	56600
Static load rating, Load direction III: lateral load (III C 0)	89150
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Standard carriage for six-row linear recirculating ball bearing and guideway assembly

Suffix description

RROC	Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
V2	Preload Class 2
G3	Precision Class 3
