INA KWVE15-B-EC-V1-G1 Rulman

Özellikler

Marka	INA
Ürün No	KWVE15-B-EC-V1-G1 INA
Üretici No	0197546550220
Alternatif Kodu	KWVE15-B-EC-G1-V1
EAN	4054362961246
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	15
Dış (D) MM	52
En (B) MM	44,5
İç (d) Inch	0.5906
Dış (D) Inch	2.0472
En (B) Inch	1.752
Ağırlık	0.13 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	52
Overall length carriage (L) mm	44,5
Dynamic load rating (C)	4900
Static load rating (C 0)	8300
Static moment rating about X axis (M 0x)	86
Static moment rating about Y axis (M 0y)	35
Static moment rating about Z axis (M 0z)	35
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row

Suffix description

B	Version
EC	Expanded Design, Short Carriage (Carriage Without Screw Threads)
V1	Slight Preload
G1	Precision Class 1
