INA KWVE15-B-ESC-RROC-V1-G3 Rulman
Fiyatı: 2,080.78 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE15-B-ESC-RROC-V1-G3 INA |
| Üretici No | 0781963370240 |
| EAN | 4054362961819 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 15 |
| Dış (D) MM | 34 |
| En (B) MM | 44,5 |
| İç (d) Inch | 0.5906 |
| Dış (D) Inch | 1.3386 |
| En (B) Inch | 1.752 |
| Ağırlık | 0.12 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 34 |
| Overall length carriage (L) mm | 44,5 |
| Dynamic load rating (C) | 4900 |
| Static load rating (C 0) | 8300 |
| Static moment rating about X axis (M 0x) | 86 |
| Static moment rating about Y axis (M 0y) | 35 |
| Static moment rating about Z axis (M 0z) | 35 |
| B | Version |
| ESC | Expanded Design, Short, Narrow Carriage |
| RROC | Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free |
| V1 | Slight Preload |
| G3 | Precision Class 3 |
