INA KWVE15-B-ESC-V1-G3 Rulman

Özellikler

Marka	INA
Ürün No	KWVE15-B-ESC-V1-G3 INA
Üretici No	0170654610240
Alternatif Kodu	KWVE15-B-ESC-G3-V1
EAN	4054362962120
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	15
Dış (D) MM	34
En (B) MM	44,5
İç (d) Inch	0.5906
Dış (D) Inch	1.3386
En (B) Inch	1.752
Ağırlık	0.12 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	34
Overall length carriage (L) mm	44,5
Dynamic load rating (C)	4900
Static load rating (C 0)	8300
Static moment rating about X axis (M 0x)	86
Static moment rating about Y axis (M 0y)	35
Static moment rating about Z axis (M 0z)	35
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set

Suffix description

B	Version
ESC	Expanded Design, Short, Narrow Carriage
V1	Slight Preload
G3	Precision Class 3
