INA KWVE15-B-H-RROC-V1-G3 Rulman
Fiyatı: 2,258.01 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE15-B-H-RROC-V1-G3 INA |
| Üretici No | 0781970820240 |
| Alternatif Kodu |
KWVE15-B-H-RROC-G3-V1 |
| EAN | 4054362963233 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 15 |
| Dış (D) MM | 34 |
| En (B) MM | 61,2 |
| İç (d) Inch | 0.5906 |
| Dış (D) Inch | 1.3386 |
| En (B) Inch | 2.4094 |
| Ağırlık | 0.2 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 34 |
| Overall length carriage (L) mm | 61,2 |
| Dynamic load rating (C) | 7200 |
| Static load rating (C 0) | 14500 |
| Static moment rating about X axis (M 0x) | 150 |
| Static moment rating about Y axis (M 0y) | 100 |
| Static moment rating about Z axis (M 0z) | 100 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-H, high, narrow carriage, four-row |
| B | Version |
| H | High Carriage |
| RRF | Components Coated With Corrotect® Containing Cr(VI) |
| V1 | Slight Preload |
| G3 | Precision Class 3 |
