INA KWVE15-B-H-RROC-V2-G3 Rulman

Özellikler

Marka	INA
Ürün No	KWVE15-B-H-RROC-V2-G3 INA
Üretici No	0781970820340
Alternatif Kodu	KWVE15-B-H-RROC-G3-V2
EAN	4054362963240
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	15
Dış (D) MM	34
En (B) MM	61,2
İç (d) Inch	0.5906
Dış (D) Inch	1.3386
En (B) Inch	2.4094
Ağırlık	0.2 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	34
Overall length carriage (L) mm	61,2
Dynamic load rating (C)	7200
Static load rating (C 0)	14500
Static moment rating about X axis (M 0x)	150
Static moment rating about Y axis (M 0y)	100
Static moment rating about Z axis (M 0z)	100
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-H, high, narrow carriage, four-row

Suffix description

B	Version
H	High Carriage
RRF	Components Coated With Corrotect® Containing Cr(VI)
V2	Preload Class 2
G3	Precision Class 3
