INA KWVE20-B-ES-V2-G3 Rulman
Fiyatı: 2,339.42 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE20-B-ES-V2-G3 INA |
| Üretici No | 0586740120340 |
| Alternatif Kodu |
KWVE20-B-ES-G3-V2 |
| EAN | 4054362969181 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 20 |
| Dış (D) MM | 42 |
| En (B) MM | 71,4 |
| İç (d) Inch | 0.7874 |
| Dış (D) Inch | 1.6535 |
| En (B) Inch | 2.811 |
| Ağırlık | 0.315 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 42 |
| Overall length carriage (L) mm | 71,4 |
| Dynamic load rating (C) | 13100 |
| Static load rating (C 0) | 27000 |
| Static moment rating about X axis (M 0x) | 332 |
| Static moment rating about Y axis (M 0y) | 240 |
| Static moment rating about Z axis (M 0z) | 240 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-ES, carriage for four-row linear ball bearing and guideway assembly, expanded type, narrow design |
| B | Version |
| ES | Expanded Design, Narrow Carriage |
| V2 | Preload Class 2 |
| G3 | Precision Class 3 |
